Heat dissipation method: Natural convection cooling

Audio Input

Input: 1 x Dante

Input Connector: 1 x RJ45 Port

Audio Output

Output: 1 x Power Amplifier, 1 x Stereo Audio

Output Connector: 1 x Plug-in Terminal (5P, 3.81mm)

1 x Plug-in Terminal (4P, 5.08mm)

Audio Input Parameters

Dante Input: 24-bit uncompressed, selectable sampling rates of 44.1 kHz, 48 kHz and 96 kHz

Main Output Parameters

Output Impedance: 4/8Ω Speaker Output

Rated Power Output: Stereo Output 2x30W@4 Ω or 2x30W@8 Ω

Bridge Output 1x60W@8 Ω

Frequency Response: 20Hz ~ 20kHz, ± 3dB

Signal-to-Noise Ratio (SNR): DC Power: >85dB (A-weighted)

Total Harmonic Distortion + Noise (THD+N): 1/8 Rated Power Output:<0.05% at 8Ω, Normal Power Output: 0.5%, LPF 20kHz, clipping low 3dB

Line Output Performance

Rated Output Level: 1.0Vrms ± 0.5dB

Maximum Output Level: 3V = 16dB, above -10dBV (316mV) nominal electrical line signal

Frequency Response: 20Hz ~ 20KHz, ± 3dB

Signal-to-Noise Ratio (SNR): >85dB (A-weighted), 20Hz ~ 20KHz bandwidth

Total Harmonic Distortion + Noise (THD+N):<0.05% (-80 dB)

Crosstalk Isolation: >70dB Conventional

Amplifier type: Class D

Power supply: DC 24V, 2.71A

IEEE 802.3at Type 2, PoE+

AC power consumption: 18W at 1/8 maximum output level

85W at maximum output level

Operating temperature: -10°C to +55°C

Storage temperature: -25°C to +70°C

Storage humidity: 10% to 90%

Dimensions (W x H x D): 166mm x 44mm x 160mm

Net weight: 895g
