Product Features:

1.The processor chip adopts the ADI architecture and is equipped with a floating-point operation engine of no less than 40 bits. It offers a flexible software architecture for configuration.

2.8-channel analog audio input channel for microphone/line level; 8-channel analog audio output channel for line level.

3. Adopt RJ45 network interface;

4. Customized operation software enables more flexible configuration and allows control of different specifications of DSPs.

5. The built-in USB sound card enables audio signal transmission when connected to a computer, supporting both recording and remote meetings.

6. The front panel features a high-resolution graphic OLED display for showing system status and audio settings. All operations such as scene switching and volume adjustment can be accessed through the swivel knob.

7. It features a soft control switch with dual-color indication (red for standby, green for on), and it can be switched by long press.

8. Provide a customizable user interface for end users, enabling centralized control of multiple devices. It is possible to control third-party devices through the local UDP, RS232, and RS485 interfaces. The control software code can also be viewed.

9. Equipped with processing modules such as AFC (feedback suppression) AEC echo cancellation, ANS (noise suppression), AGC (automatic gain) gain sharing threshold, automatic mixing, and deflector;

10. Each channel has independent adaptive feedback suppression, which automatically detects the feedback points and suppresses them.

11. With a 20 x 17 matrix;

12. Full-function matrix mixing, with adjustable input mixing levels;

13.32 sets of scene presets, which can be expanded to 50 sets. Scenes can be called upon at will for use, facilitating different application scenarios.

14. It has the function of permission setting, allowing the establishment of super administrator, general user and visitor permissions.

15. Dual-machine hot backup can be set up as master-slave. All configurations of the master machine are backed up to the slave machine in real time. When the master machine fails and disconnects, the slave machine outputs audio in real time.

16.8 GPIOs can be independently configured for input and output. When configured as input, they can also be used as an independent ADC.

17. The system that supports channel BE, LINK and packet functions, automatic mixing, paging, routing and allocation, microphone/line processing, automatic gain control (AGC), and room linkage functions provides the necessary DSP processing.

18. It has an editable operation interface. Each channel can be equipped with a deflection device, noise gain compensation, 5-band parametric equalization, 12-band parametric equalization, 10-band graphical equalization, 15-band graphical equalization, and 31-band graphical equalization configuration.

19. Supports R232 & UDP central control. The UDP port can be freely set. The control software code can also be viewed.

20. Intelligent automatic camera tracking function;

21. Fire linkage function;

22. Multiple control methods are available, which can be managed through web pages, mobile phones, tablets, key panels, touch panels, etc.
