Product Features:

1. The processor chip adopts the ADI architecture, with a floating-point operation engine of no less than 40 bits, providing a freely configurable software architecture;

2. The panel is made of advanced materials, reflecting an elegant and high-end atmosphere;

3. The host has an OLED color screen, which alternately displays the device name, IP address, version firmware, and input/output channel signals;

4. It has up and down buttons for page flipping to view device information, and the LED channel signal indicator can display red, green, and yellow signals;

5. It has a soft control switch with red and green dual-color indication, where red indicates standby and green indicates startup. It can be switched by long press;

6. It can provide an interface for end users to realize centralized control of multiple devices. It can control third-party devices through the UDP, RS232, and RS485 of this machine, and can view the control software code;

7. Each channel has independent adaptive feedback suppression, automatically discovers feedback points, and automatically suppresses them. It has processing modules such as AFC (feedback suppression), AEC (echo cancellation), ANS (noise suppression), AGC (automatic gain) gain sharing threshold automatic mixing, etc.;

8. It has a 36x33 matrix, full-function matrix mixing, and the input mixing level can be adjusted;

9. 16 balanced microphone/line inputs, 16 balanced audio outputs, using Phoenix connector interface;

10. 16 Dante inputs, 16 Dante outputs, using RJ45 network interface;

11. Customized operation software, making configuration more flexible, capable of controlling different specifications of DSP;

12. 8 GPIOs can be independently configured for input and output. When configured as input, it can be used as an independent ADC;

13. 32 scene presets, which can be expanded to 50 groups. It can be called and used arbitrarily, convenient for different usage scenarios;

14. It has permission and password setting functions, capable of setting super administrator, general user, and visitor permissions;

15. It can set master-slave dual-machine hot backup. All configurations of the host are backed up to the slave machine in real time. When the host fails and disconnects, the slave machine outputs audio in real time;

16. It supports channel be, LINK and group functions;

17. It has an editable operation interface. Each channel can select a deflector, noise gain compensation, 5-section parametric equalization, 12-section parametric equalization, 10-section graphical equalization, 15-section graphical equalization, 31-section graphical equalization configuration;

18. Intelligent automatic camera tracking function;

19. Fire linkage function;

20. Multiple control methods, such as through web pages, mobile phones, tablets, button panels, touch panels, etc. for management.
